Sealing plastic components presents a challenge rigid materials don’t have to deal with. Plastics flex, expand, and contract continuously in service, and a gasket that can’t move with them eventually stops sealing at all.
Why Traditional Gaskets Fail on Plastic Assemblies
Traditional gasket materials are prone to compression set — over time, a compressed gasket permanently loses its original shape and stops rebounding to fill the gap it was compressed into. On a rigid metal assembly, that gradual loss of sealing force is a slow problem. On a plastic assembly, where the substrate itself is also flexing and shifting with temperature and mechanical load, a gasket that has already taken a permanent set has effectively no ability to track the substrate’s movement, and the seal fails well before the surrounding plastic shows any visible wear.
A Gasket Material Engineered for Memory and Resilience
Incure formulates highly resilient, low-viscosity gasket materials specifically to resist compression set on plastic assemblies. This class of material combines high resilience with strong memory retention, meaning it returns to its original shape after being compressed rather than gradually flattening out over repeated cycles. Elongation as high as 560%, paired with a soft cured hardness in the D17–D27 range, lets the gasket deform readily under compression and then rebound reliably, which is exactly the behavior a compression-set-resistant seal needs.
That combination of properties prevents the compression set that ends a traditional gasket’s useful life, keeping the seal air-tight through years of the expansion and contraction cycles typical of plastic assemblies. A low viscosity around 400 cP allows precise, clean application into intricate geometries, and a transparent, broadly plastic-compatible formulation suits a wide range of housing designs.
Manufacturers sealing plastic enclosures or assemblies can Email Us with the gasket geometry and expected duty cycle for a formulation recommendation.
Testing for Compression Set, Not Just Initial Seal Force
Most gasket qualification testing measures sealing force at the moment of assembly, which tells you almost nothing about how the seal will perform after a year of thermal cycling. Compression-set testing — measuring how much of the original thickness a gasket recovers after extended compression at elevated temperature — is a far better predictor of long-term sealing performance, and it’s the test that actually distinguishes a resilient gasket material from one that will quietly fail within a product’s warranty period.
Engineers designing gasket geometry for assemblies with significant thermal expansion differences between materials may find how CTE mismatch drives adhesive bond failure useful background, since the same mismatch that stresses adhesive bonds also determines how much movement a gasket needs to accommodate over a thermal cycle. Teams also using UV-curable adhesives elsewhere in the same plastic assembly may find UV glue vs epoxy for transparent bonding a useful reference for choosing compatible chemistries across the build.
Practical Design Guidance for Plastic Gasket Applications
Getting reliable long-term performance from a resilient gasket material depends on designing the compression ratio correctly during assembly — too little compression underutilizes the material’s rebound capability, while too much can accelerate degradation even in a highly resilient formulation. Surfaces should be clean and free of mold-release residue before gasket application, since contamination reduces adhesion and can create localized leak paths regardless of how resilient the gasket material itself is. Validating the seal under accelerated thermal cycling that reflects the assembly’s real service environment remains the most reliable way to confirm long-term sealing performance before committing to production.
Accounting for Plastic Creep Alongside Gasket Resilience
A resilient gasket material only solves half of the long-term sealing equation on a plastic assembly, since the plastic housing itself can also creep — gradually deforming under sustained compressive load — over the product’s service life. A gasket engineered to resist compression set still needs a housing design that limits how much the plastic itself relaxes over time, since housing creep alone can open a sealing gap even when the gasket material is performing exactly as specified. Reviewing the plastic substrate’s own long-term creep behavior alongside the gasket’s compression-set resistance gives a more complete picture of the assembly’s actual sealed life than evaluating the gasket material in isolation.
Assembly torque and fastener selection also affect how consistently a resilient gasket performs across a production run. Under-torqued fasteners fail to achieve the gasket’s intended compression ratio from the start, while over-torqued fasteners can accelerate plastic creep in the housing around each fastening point. Specifying and verifying assembly torque as part of the sealing qualification — not just as a general mechanical assembly instruction — closes a gap that often goes unnoticed until inconsistent sealing performance shows up across a production lot.
A gasket that actually bounces back after every compression cycle is what keeps a plastic assembly sealed for its full service life, not just at the point of manufacture. Contact Our Team to discuss a gasket material strategy for your plastic assembly.
