Lightguide Terminators — Incure LGT-Series™
Precision-machined angled tip attachments for UV spot curing lightguides. Available in 60° and 90° exit angles with Ø5mm and Ø8mm apertures — enabling UV light delivery to bond faces and cavities inaccessible to a straight lightguide.
Model Comparison
Side-by-side specifications across the Incure lightguide terminator range.
| Lightguide Terminators | ||||
|---|---|---|---|---|
| Specification | LGT-90-590° · Ø5mm | LGT-90-890° · Ø8mm | LGT-60-560° · Ø5mm | LGT-60-860° · Ø8mm |
| Image |
|
|
|
|
| Exit Angle | 90° | 90° | 60° | 60° |
| Aperture Diameter | Ø5mm | Ø8mm | Ø5mm | Ø8mm |
| Compatible Lightguide Core | Ø5mm | Ø8mm | Ø5mm | Ø8mm |
| Body Material | Aluminum | Aluminum | Aluminum | Aluminum |
| Compatible Systems | UV spot curing systems LLG-1P-5 and compatible |
UV spot curing systems LLG-1P-8 and compatible |
UV spot curing systems LLG-1P-5 and compatible |
UV spot curing systems LLG-1P-8 and compatible |
| Best For | Perpendicular access Precision spot |
Perpendicular access Wide spot |
Oblique access Precision spot |
Oblique access Wide spot |
Order the Incure LGT-Series™
Incure LGT-Series™ precision-machined angled tip attachments for UV spot curing
lightguides. Available in 60° and 90° exit angles with Ø5mm and Ø8mm apertures.
| Model | Image | Description | Specifications | TDS | Order 4–6 WEEKS ARO |
|---|---|---|---|---|---|
|
LGT-Series™
LGT-90-5
90° · Ø5mm
|
|
Incure LGT-Series™ LGT-90-5 is a 90-degree angled lightguide terminator with a Ø5mm aperture. Attaches to the delivery end of a Ø5mm UV lightguide and redirects UV light at a right angle to the lightguide axis. Engineered for curing on vertical bond faces, side-wall joints, and assembly geometries where straight-line access is not possible. |
Exit Angle: 90° Aperture: Ø5mm Compatible Core: Ø5mm Body: Aluminum Compatible: LLG-1P-5 & standard Ø5mm lightguides |
TDS | |
|
LGT-Series™
LGT-90-8
90° · Ø8mm
|
|
Incure LGT-Series™ LGT-90-8 is a 90-degree angled lightguide terminator with a Ø8mm aperture. Provides a wider UV spot at a right-angle exit for larger bond joint areas on perpendicular surfaces. Compatible with Ø8mm UV lightguide systems requiring right-angle access in high-throughput production or wider-area spot delivery. |
Exit Angle: 90° Aperture: Ø8mm Compatible Core: Ø8mm Body: Aluminum Compatible: LLG-1P-8 & standard Ø8mm lightguides |
TDS | |
|
LGT-Series™
LGT-60-5
60° · Ø5mm
|
|
Incure LGT-Series™ LGT-60-5 is a 60-degree angled lightguide terminator with a Ø5mm aperture. Delivers a precision UV spot at an oblique 60° exit angle — suited to recessed bondlines, angled cavities, and complex assembly fixtures where a right-angle approach is mechanically obstructed. Compatible with Ø5mm UV lightguide systems. |
Exit Angle: 60° Aperture: Ø5mm Compatible Core: Ø5mm Body: Aluminum Compatible: LLG-1P-5 & standard Ø5mm lightguides |
TDS | |
|
LGT-Series™
LGT-60-8
60° · Ø8mm
|
|
Incure LGT-Series™ LGT-60-8 is a 60-degree angled lightguide terminator with a Ø8mm aperture. Combines the oblique 60° exit angle with a wider Ø8mm spot for curing larger bond areas at angled geometries. Ideal for wider-aperture lightguide systems operating in assembly applications where the approach angle is constrained. |
Exit Angle: 60° Aperture: Ø8mm Compatible Core: Ø8mm Body: Aluminum Compatible: LLG-1P-8 & standard Ø8mm lightguides |
TDS |
Precision UV Delivery at Any Angle
Angled lightguide terminators extend the reach of UV spot curing systems
into assembly geometries where straight-line UV delivery is not possible.
Frequently Asked Questions
Common questions about Incure lightguide terminators.
-
A lightguide terminator is a precision-machined tip attachment that mounts onto the delivery end of a UV fiber optic lightguide. It redirects the UV light beam at a specific exit angle — 60° or 90° — relative to the lightguide axis, enabling curing in confined spaces, on vertical surfaces, and in assembly cavities that are inaccessible to a straight lightguide configuration.
-
A 90° terminator redirects UV light at a right angle to the lightguide axis — used when curing perpendicular to the direction of approach, such as vertical bond faces, side walls of housings, or PCB edge joints. A 60° terminator directs UV at an oblique 60° angle for recessed bondlines and angled cavities where a full right-angle approach is physically obstructed. Choose based on the geometric relationship between your lightguide approach axis and the target bond face.
-
Select the aperture that matches the core diameter of your lightguide. The Ø5mm terminator is suited to precision spot delivery on small bond joints and narrow geometries. The Ø8mm terminator provides a wider spot for larger bond areas and higher UV energy throughput. Mismatching the aperture to your lightguide core will cause UV energy loss at the connection interface.
-
Incure LGT-Series™ lightguide terminators are compatible with standard UV spot curing lightguides with Ø5mm or Ø8mm exit apertures — including Incure liquid light guide models LLG-1P-5 and LLG-1P-8 and compatible third-party UV lightguides with matching port dimensions. Contact support@uv-incure.com with your current lightguide model for a compatibility confirmation before ordering.
-
Use a lightguide terminator when the bondline is on a surface perpendicular or oblique to the direction the lightguide can physically approach. Common situations include vertical assembly surfaces, inside enclosed housings, alongside PCB edges, in catheter tip jigs, and in robotic fixtures where the light source must approach from a fixed direction but the cure site is at an angle.
-
Lightguide terminators are widely used in electronics assembly (bonding along PCB edges and inside component housings), medical device manufacturing (catheter bonding, needle assembly), optical assembly (prism and lens bonding in confined fixtures), and automotive sensor manufacturing where bond faces are often on vertical or angled surfaces within a larger assembly.
